پنجره-Window SlimLine 68
افزودن به پروژه های شخصی|
LedBim Category: |
Window |
|
LedBim Sub Category: |
Opening Hinge |
|
IFC classification: |
Window |
|
UNSPSC name: |
Windows |
|
UNSPSC code: |
301716 |
|
Uniclass 1.4 Code: |
JL10 |
|
Uniclass 1.4 Description: |
Windows |
|
Uniclass 2.0 Code: |
PR-59-97 |
|
Uniclass 2.0 Description: |
Windows |
|
Uniclass 2015 Code: |
EF_25_30 |
|
Uniclass 2015 Description: |
Doors and windows |
|
NBS Reference Code: |
59-97 |
|
NBS Reference Description: |
Windows |
|
CSI MasterFormat 2014 Code: |
08 51 13 |
|
CSI MasterFormat 2014 itle: |
Aluminum Windows |
|
OmniClass Number: |
23-17 13 00 |
|
OmniClass itle: |
Windows |
|
CSI UniFormat II Code: |
B2020 |
|
CSI UniFormat II itle: |
Exterior Windows |
|
Name |
Value |
|
Air Infiltration |
600 Pa |
|
Cladding - Exterior |
Aluminium |
|
Cladding - Interior |
Aluminium |
|
Color - Exterior |
RAL |
|
Color - Interior |
RAL |
|
Depth |
68 |
|
Frame Material |
Aluminum |
|
Frame hickness |
68 |
|
Height |
— 1500 mm |
|
R Value |
47 |
|
Static Water Pressure |
1200 Pa |
|
hermal Break (Y/N) |
Yes |
|
U Value |
1.4 — |
|
Uniform Structural Wind Load |
200 |
|
Weight |
— 50 kg |
|
Width |
— 1200 mm |
